PLC

Mini PLC with connector 1x4

Planar lightwave circuit (PLC) splitter is a passive optical device. It can divide the optical signal into multiple output signals. 1xN and 2xN splitters evenly distribute optical signals from a single or dual inlet to multiple outlets, or vice versa, directing multiple optical signals into a single or two optical fibers. PLC is widely used in optical access networks (PON), data centers, and cable television systems, achieving efficient and distributable optical signals.

Introduction

Technical parameters:

Produc name	Fiber Optic Splitter	Packaging:	Carton box
Model Number:	Mini PLC 1X4	Brand Name:	SOCT
PLC type	Mini Module	Place of Origin:	Jiangsu,China
Fiber type	G657A1	OEM:	Yes
Output Adaptor:	SC APC	Delivery Time:	3-7 working days

Features

RoHS Compliant
Compact Size Design
Outstanding Reliability and Stability
Minimal Insertion Loss and Low Polarization Dependent Loss (PDL)
Broad Operating Wavelength Range: 1260nm to 1650nm
Wide Operating Temperature Range: -20°C to 70°C

Specifications

Port Configuration	1x2	1x3	1x4	1x6	1x8	1x12	1x16	1x32	1x64
Insertion Loss (dB)	4.1	6.5	7.5	10.0	10.8	12.9	13.8	17.0	21.4
Loss Uniformity (dB)	0.6	0.6	0.6	0.6	0.8	1.0	1.2	1.5	1.5
Polarization Dependent Loss(dB)	0.2	0.2	0.2	0.2	0.2	0.2	0.25	0.3	0.4
Wavelength Dependent Loss(dB)	0.3	0.3	0.3	0.3	0.3	0.3	0.5	0.5	0.5
Temperature Dependent Loss (dB)	0.4	0.4	0.4	0.4	0.4	0.4	0.5	0.5	0.5
Return Loss (dB)	UPC≥50; APC≥55
Directivity (dB)	≥55
Operating Wavelength (nm)	1260~1650
Fiber Type	G657A1 or customer specified
Operating Temperature	-40~+85
Storage Temperature	-40~+85

Profile Size

1x2;1x3;1x4;1x6;1x8	7x4x50mm or 7x4x60mm
1x12;1x16	12x4x60mm
1x32	20x6x80mm
1x64	40x6x100mm

Packing

1x2;1x3;1x4;1x6;1x8	200pcs/carton
1x12;1x16	100pcs/carton
1x32	50pcs/carton
1x64	20pcs/carton
Packing material	Plastic box (PE)
Carton Dimension (HxWxD)	435x410x410mm
